◆可选带以下功能 optional with following function:
→双极单掷 dpst (double pole single throw)
→双极双掷 dpdt (double pole double throw)

→双极双掷带中间断开 dpdt with center off

→点动方式 momentary act

→机械耐久寿命 mechanical life endurance≥5e4/1e5
→电气耐久寿命 electrical life endurance≥1e4/5e4
→最大冲击电流 max. inrush current at 250v72a
→最大冲击电流 max. inrush current at 125v108a
→接触电阻 contact resistance≤30m ohm
→绝缘电阻 insulation resistance≥7m  ohm
→基本介电强度 dielectric strength of function1500v
→加强介电强度 dielectric strength of reinforced3000v
→环境温度 ambient temperature0°c~55°c
→阻燃等级 flammabilityul 94v-0
→防护等级 protection typeip40
→适用于ii类防护器具 suitable for appliances of protection class ii

◆输入端/输出端 input side/output side:
→插片端子 plug-in terminals 4.8×0.8mm
→螺钉端子 screw terminals m3.5
