fdz倒扳开关

fdz series lever switches

产品描述product description

fdz系列是一款专用型的倒扳开关,也叫摇杆开关或拨动开关,应用于各类小家电,如:厨房搅拌机等。
fdz series are special type lever switches, commonly for used in small home appliances such as kitchen mixer, etc.

产品特征features

◆可选带以下功能 optional with following function:
→单极单掷 single pole single throw (spst)
→单极单掷点动 single pole single throw momentary act (spstm)

技术数据technical data

→机械耐久寿命 mechanical life endurance≥1e5
→电气耐久寿命 electrical life endurance≥5e4
→最大电流 max. current at 36v6a
→接触电阻 contact resistance≤30m ohm
→绝缘电阻 insulation resistance≥7m ohm
→基本介电强度 dielectric strength of function500v
→环境温度 ambient temperature0°c~85°c
→阻燃等级 flammabilityul 94v-0
→防护等级 protection typeip40
→适用于ii类防护器具 suitable for appliances of protection class ii

端子类型terminals

◆输入端/输出端 input side/output side:
→焊接端子 solder terminals 2.7×0.6mm
→线路板焊接端子 pcb soldering terminals 0.8×0.6mm
→线路板焊接端子 pcb soldering terminals 1.5×0.6mm

电气参数和认证 electric rating and certification

订货信息ordering information
