fa7-6b防尘按钮开关

fa7-6b series dustproof push-button switches

产品描述product description

fa7-6b系列是一款专用型的按钮开关,集成防尘功能,应用于各类手持式电动工具,如:电木铣、修边机等,可选带闭合自锁功能。
fa7-6b series are special type push-button switch, integrated dustproof, popular for used in portable power-tools such as electric routers, etc. optional with self-lock function.

技术数据technical data

→机械耐久寿命 mechanical life endurance≥1e5
→电气耐久寿命 electrical life endurance≥5e4
→最大冲击电流 max. inrush current at 250v60a
→最大冲击电流 max. inrush current at 125v96a
→接触电阻 contact resistance≤30m ohm
→绝缘电阻 insulation resistance≥7m  ohm
→基本介电强度 dielectric strength of function1500v
→加强介电强度 dielectric strength of reinforced3000v
→环境温度 ambient temperature0°c~55°c
→阻燃等级 flammabilityul 94v-0
→防护等级 protection typeip40
→适用于ii类防护器具 suitable for appliances of protection class ii

端子类型terminals

◆输入端 input side:
→接线柱端子 pillar terminals φ=3mm
◆输出端 output side:
→接线柱端子 pillar terminals φ=3mm

电气参数和认证 electric rating and certification

订货信息ordering information
