dsd防尘直流信号开关

dsd series dustproof dc trigger switches

产品描述product description

dsd系列是一款迷你型的直流信号开关,集成防尘功能,是特别为直流无刷充电式电动工具设计的,可适用于没有换向要求的直流无刷电动工具:无刷充电式曲线锯、无刷充电式往复锯等。
dsd series are one mini-type dc signal switches, integrated dustproof, designed specially for used in brushless dc power-tools without reversing such as: brushless cordless jig saws, brushless cordless reciprocating saws, etc.

产品特征features

◆可选带以下功能或附件:
→信号通断带电位器输出功能
→信号刹车
◆optional with the function or accessories as follows:
→signal on-off version with linear potentiometer signal brake

技术数据technical data

→机械耐久寿命 mechanical life endurance≥1e5
→电气耐久寿命 electrical life endurance≥5e4
→最大电流 max.current at 130vd.c0.1a
→接触电阻 contact resistance≤30m ohm
→绝缘电阻 insulation resistance≥7m ohm
→基本介电强度 dielectric strength of function500v
→加强介电强度 dielectric strength of reinforced500v
→环境温度 ambient temperature0°c~55°c
→阻燃等级 flammabilityul 94v-0
→防护等级 protection typeip40

◆开关内部电子部分在相应使用中一并做过相关测试, 本开关适合做二类器具开关使用.

◆the electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class ii.

端子类型terminals

◆输入端/输 出端 input side/output side:
→导线端子 wire terminal
→带插头导线端子 wire terminal with plug
★本产品荣获外观设计专利,zl202230756713.6
★industrial design patented with the no. is zl202230756713.6

电气参数和认证 electric rating and certification

订货信息ordering information
